AC motor capacitor for air condensor with UL CE ISO approve from China manufacturer

AC motor capacitor for air condensor with UL CE ISO approve

Price:	0.3~5.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Anhui, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: CBB65 capacitor

Production Capacity: 10000 pieces/day

Delivery Date: 3~10 days

Package Type: Throught Hole

Brand Name: SaiFu/CSF/OEM

Rated Voltage: 200VAC~660VAC

AC capacitor filling: Castor Oil

Means of Transport: Ocean,Air

Packing: AC capacitors with standard...

Application: AC / Motor

Type: Polypropylene Film Capacito...

Capacitance: 3UF~120UF

Operating Temperature: -40°C~+85°C

AC capacitor can: aluminum can

1. High insulation resistance capacitors
2. Stable reliability AC capacitors
3. Anti-explosion motor capaciotors

Application

Applied to the starting and better working of sing-phase motor in 50Hz(60Hz) frequency AC power system.

Specification

ac capacitor items	normial value
capacitance	3UF~120UF
voltage	200VAC~660VAC
Operating temperature	-40 °C ~+70 °C /85 °C
I.R	3000s(MΩ·UF)
Dielectric dissipation factor	tgδ≤0.0020 (50Hz~100Hz)
standard	IEC60252 GB/T 3667-2008
Anticipated operating life	10000h(Class B) 3000h(Class C) 30000h(Class A)
Security level	P1/P2
apacitance tolerance	±5%

Application requirements
Altitude:≤2000m
Residual voltage while loading: less than 10% of rated voltage.
Allowed maximum voltage: less than 1.1 times of rated voltage.
Permissible maximum current: less than 1.3 times of rated current.

Other product specifications(if you need, you can contact me)

Rated voltage(VAC)	Nominal capacitance(μF)	Size(mm)
		D	H
200,250,370,400,440, 450,600,700,1200	3,4,5,7.5,10,12.5,15,17,20,22.5, 25,30,35,40,45,50,55,60,70,80,100, 25+5, 30+5, 35+5, 50+5, 60+5, 70+5, 80+5…	40,45,50,55, 60,63.5, 5232,7145	60,65,70,75,80,85,90, 95,100,105,110,115, 120,125,135,138
